Add product images carousel here.Delivering outstanding value, together with class-leading performance and security, the Alitherm 400 HD window system includes a range of solutions for large format casement windows for residential and light commercial applications. Options include fixed, top hung, and side hung casements, each with internally beaded vent frames.
APPLICATION
- RESIDENTIAL AND LIGHT COMMERCIAL APPLICATIONS
- NEW BUILD AND REFURBISHMENT PROJECTS
WINDOWS
- LARGE FORMAT
- SIDE HUNG, OPEN OUT CASEMENTS
- TOP HUNG, OPEN OUT CASEMENTS
- FIXED CASEMENTS
DESIGN LIMITATIONS
| WINDOW TYPE | MAX WIDTH MM | MAX HEIGHT MM | FRAME DEPTH MM | MAX WEIGHT KG | DOC L | TYPICAL U VALUE | GLAZING UNITS MM |
|---|
| TOP HUNG | 1680 | 2500 | 70 | 180 | YES | 1.4 W/m2K | 28,32,36,40,44,48,55 |
| SIDE HUNG | 1000 | 1724 | 70 | 40/55 | YES | 1.4 W/m2K | 28,32,36,40,44,48,55 |
| FIXED | 2100 | 2100 | 70 | - | YES | 1.4 W/m2K | 28,32,36,40,44,48,55 |
