Product information

Delivering a great combination of strength, elegance and performance, this system incorporates the original Visoglide outer frame to deliver excellent value. Featuring Smart’s co-extruded glazing gasket, with the profiles and beads supplied with the glazing gasket pre-extruded into the profile, fabrication and installation are also fast and efficient.

FEATURES & SPECIFICATION

  • 1.6 W/m2K (1.0 CENTRE)
  • 1.3 W/m2K (0.7 CENTRE)
  • PAS24:2022
  • BS Kitemark
  • Document L Compliant
  • Quick Glaze Bead
  • Coex gasket sash
  • Slim interlock

BrandVisoglide Plus
MaterialAluminium Polyamide
Dual ColourYes
Thermally BrokenYes
NBS AvailableYes
U Value1.6 W/m2K (1.0 centre)
Document L CompliantYes
KitemarkYes
BS 6375-1:2009Yes
BS 6375-2:2009Yes
BS 7950:1997Yes
BS 4873Yes
CWCTYes
Glazing (mm)Up to 38mm
Frame Depth (mm)102.5
