Product information
MC600 PLUS
DESIGNING PRODUCT SOLUTIONS FOR:
| Commercial and residential buildings up to three stories high |
| Ground floor treatment |
| New build and refurbishment projects |
| Butt joints allowing use of same extrusion for mullion and transom |
| Fully CWCT tested |
| Options for sloped transoms |
MC600 Plus is a CWCT tested, stick build curtain wall system, developed to provide specifiers and clients with an elegant, practical and economic glazed façade solution.
Perfect for commercial and domestic buildings up to three stories high, as well as ground floor treatments for low-rise commercial premises, MC600 Plus has been designed for quick and easy fabrication and installation.
Featuring a new improved end pad design, as well as improved drainage detail, MC600 Plus benefits from an interchangeable transom/mullion profile, which enables fabricators to use the same profile section for both purposes. This not only fully optimises material usage but also ensures consistent sight lines.
| STYLE | STICK BUILD CURTAIN WALL |
| SINGLE-STOREY | YES |
| MULTI-STOREY | MAX 3 STOREYS |
| CWCT TESTED | YES |
| DOCUMENT L COMPLIANT | YES |
| AIR PERMEABILITY CLASSIFICATION | CLASS 4, 600PA |
| WATER TIGHTNESS CLASSIFICATION | CLASS R7, 600PA |
| RESISTANCE TO WIND CLASSIFICATION | CLASS 2400, 2400PA |
| TYPICAL SIGHTLINES (MM) | 54.5-56.5 |
| BACK BOX OPTIONS (MM) | 50, 75, 100, 120, 125, 150, 170, 225 |
| GLAZING UNITS (MM) | 28, 30, 32, 34, 36, 40, 42, 44, 50, 52, 54 |
(For details outside these parameters contact Smart Technical Dept)
| Brand | MC |
| Material | Aluminium Polyamide |
| Dual Colour | Yes |
| Thermally Broken | Yes |
| NBS Available | Yes |
| Document L Compliant | Yes |
| CWCT | Yes |
